CTEK MXS 10

    Download CTEK MXS 10 User Manual

Powerful professional charging for workshops
The ultimate charger
The MXS 10 gives you state of the art technology and is ideal for professional use in workshops for caravan, RV, boat and car batteries.
The MXS 10 is a fully automatic 8-step charger that delivers 10A to 12V batteries from 20-200Ah and is also suitable for maintenance charging up to 300Ah. It includes battery diagnosis to establish whether your battery can receive and retain a charge, a Recond mode for restoring and reconditioning stratified and deeply discharged batteries, a winter program for charging in cold weather and an AGM option which maximises the performance life of most Stop/Start batteries. The MXS 10 also has a temperature sensor for optimised charging and it can even be used as a power supply source for 12V equipment.
Fully automatic ‘connect and forget’ 8 step charging
Charges batteries from 20-200Ah
Temperature sensor, AGM and Recond programs
Power supply for 12V equipment
2-year warranty

The MXS 10 is a charger that offers state of the art technology. It is ideal for professional use and excellent in workshops, caravans, RVs, boats or cars. The MXS 10 is perfect for solving a broad range of battery problems. It offers features such as battery diagnosis that shows if a battery can receive and retain a charge, a special reconditioning function that restores stratified and deeply discharged batteries, unique maintenance charging and a temperature sensor for optimised charging regardless of the weather conditions. It also has a power supply mode which allows the battery to be disconnected from the vehicle without losing important configurations. The unique display allows the user to follow the entire charging process.

The MXS 10 is a fully automatic 8-step charger that delivers 10A to 12V batteries from 20–200Ah and is suitable for maintenance charging up to 300Ah. The charger is IP 65 classified (splash and dust proof), designed to protect vehicle electronics and non-sparking, reverse polarity protected and short-circuit proof. It is delivered with a 2-year warranty.

Volt 12V
Rated Voltage AC 220–240VAC, 50–60Hz
Charging voltage NORMAL: 14.4V, COLD/AGM: 14.7V, RECOND: 15.8V, SUPPLY: 13.6V
Min battery voltage 2.0V หากแบตเตอรี่ไฟต่ำกว่า 2V เครื่องชาร์จจะไม่ทำงาน
Charging current 10A max
Current, mains 1.0A rms (at full charging current)
Back current drain <1Ah/month
Ripple <4%
Ambient temperature -20°C to +50°C, output power is reduced automatically at high temperatures
Charger type 8 step, fully automatic charging cycle
Battery types All types of 12V lead-acid batteries (WET, MF, Ca/Ca, AGM and GEL)
Battery capacity 20–200Ah, up to 300Ah for maintenance
Dimensions 197 x 93 x 49mm (L x W x H)
Insulation class IP65
Weight 0.8kg

2-year warranty

CTEK guarantee to the buyer by the name indicated on the receipt of APRTECH only guarantee can not be transferred to others. The warranty covers only the disorders caused by abnormal production of materials used in production within a period specified by the box from the date of purchase. The customer must return the product at the point of sale, along with a receipt. To guarantee an end when the Smart battery charger has been opened or tampered or used carelessly or repaired by other than CTEK SWEDEN AB or its authorized representative. One of the screws on the underside of the charger Sealed. Detachment or break the seal constitutes cancellation guarantee. Not guaranteed beyond the conditions set out in this. And is not responsible for damages other than those set forth above, such damages are affected by the damage. (Consequential damages) Moreover, CTEK SWEDEN AB and APRTECH no obligation to warranty except as specified herein.
